[Self-Diagnostic Setting]
Overview
Manually execute the self-diagnostic test that checks for problems with the firmware and device data.
Tips
- If [Enhanced Security Mode] is set to [ON], a self-diagnostic test is automatically performed when this system is turned on.
Tips
The items to be diagnosed are as follows.
- [Firmware Diagnosis]: Diagnoses whether the firmware data is corrupted.
- [Device Diagnosis]: Diagnoses the operation of the HDD, SSD, and non-explosive memory installed in this system.
Reference
- For details about [Enhanced Security Mode], refer to [Enhanced Security Mode].
Setting Procedure
1
Press [Firmware Diagnosis] or [Device Diagnosis].
A self-diagnostic test of the selected item is performed.
2
If there are no security-related problems after diagnosis is completed, [OK] is displayed.
If there are any security-related problems, an error occurs. Contact the relevant service center for help to recover from an error.
